Outboard Engine Shaft Lengths

Understanding Outboard Motor Shaft Lengths

Outboard motors are a vital component of many RIBs and Inflatables, providing the propulsion needed for movement across the water. One of the critical aspects to consider when selecting an outboard motor is the shaft length. The shaft length must match the transom height of the boat to ensure optimal performance and safety. The main categories of outboard motor shaft lengths are short shaft, long shaft, extra long shaft, and extra extra long shaft. This post explores these different shaft lengths, their typical applications, and provides a table demonstrating the available lengths.

Short Shaft Outboard Motors

Short Shaft outboard motors typically have a shaft length of around 15 inches (38 cm). These motors are designed for boats with a transom height of approximately 15 inches. Short shaft motors are commonly used on smaller boats, such as inflatable boats, tenders, and small dinghies. The shorter shaft length ensures that the propeller is adequately submerged in the water, providing efficient propulsion and minimising the risk of cavitation (air bubbles forming around the propeller, reducing its effectiveness).

Advantages of Short Shaft Motors

* Lightweight and Portable - Short shaft motors are generally lighter and easier to handle, making them ideal for smaller boats.

* Cost-Effective - These motors are sometimes less expensive than their longer-shaft counterparts.

* Ease of Installation -  Due to their compact size, short shaft motors are easier to install and remove.

Disadvantages of Short Shaft Motors:

* Limited to Small Boats - their use is restricted to boats with low transoms.

* Performance Issues - If used on boats with higher transoms, they may suffer from performance inefficiencies and increased risk of damage.

Long Shaft Outboard Motors

Long shaft outboard motors typically have a shaft length of around 20 inches (50 cm). These motors are designed for boats with a transom height of approximately 20 inches. Long shaft motors are commonly used on medium-sized boats, such as larger RIBS, sailboats, small fishing boats, and larger inflatable boats. The longer shaft length ensures that the propeller remains submerged, even in rougher waters, providing consistent performance.

Advantages of Long Shaft Motors:

* Versatility - Suitable for a wide range of boats, including those used in choppier waters.

* Enhanced Performance - Better suited for maintaining propeller submersion, reducing cavitation.

* Stability - Provides better thrust in rough waters, improving boat handling and stability.

Disadvantages of Long Shaft Motors:

* Increased Weight - Generally heavier than short shaft motors, making them harder to transport and install.

* Higher Cost - Sometimes more expensive due to their larger size and greater versatility.

Extra Long Shaft Outboard Motors

Extra long shaft outboard motors typically have a shaft length of around 25 inches (63 cm). These motors are designed for boats with a transom height of approximately 25 inches. Extra long shaft motors are commonly used on larger boats and sailboats that require deeper submersion of the propeller for optimal performance, especially in rough seas or when heavy loads are carried.

Advantages of Extra Long Shaft Motors:

* Ideal for Rough Waters - Better performance in turbulent conditions due to deeper propeller submersion.

* Improved Thrust -  Provides more efficient propulsion for larger boats.

* Increased Stability - Enhances the stability of the boat by keeping the propeller submerged.

Disadvantages of Extra Long Shaft Motors:

* Significantly Heavier - They are heavier than both short and long shaft motors, which can complicate handling and installation.

* Higher Cost - Increased price due to their enhanced performance capabilities and larger size.

Extra Extra Long Shaft Outboard Motors

Extra extra long shaft outboard motors typically have a shaft length of around 30 inches (76 cm) or more. These motors are designed for boats with a transom height of approximately 30 inches or higher. Extra extra long shaft motors are used on large boats, commercial vessels, and some specialty applications where maximum propeller depth is crucial for performance and safety.

Advantages of Extra Extra Long Shaft Motors:

* Maximum Propeller Depth - Ensures the propeller remains submerged in the deepest and roughest waters.

* Optimal for Heavy Loads - Provides powerful thrust needed for large, heavily loaded boats.

* Best Stability - Offers the highest level of stability and performance in rough conditions.

Disadvantages of Extra Extra Long Shaft Motors:

* Heaviest Option - The most challenging to handle, install, and transport due to their size and weight.

* Most Expensive - The highest cost among outboard motor shaft lengths due to their advanced capabilities and extensive applications.

Choosing the correct shaft length for an outboard motor is crucial for ensuring optimal performance, safety, and efficiency of a boat. The shaft length must match the transom height of the boat to ensure that the propeller is properly submerged in the water. Short shaft motors are suitable for small boats, providing lightweight and cost-effective propulsion. Long shaft motors offer versatility and improved performance for a wide range of medium-sized boats. Extra long shaft motors are ideal for larger boats and rough water conditions, providing enhanced stability and thrust. Extra extra long shaft motors are designed for the largest and most demanding applications, offering maximum propeller depth and performance.

By understanding the differences between these shaft lengths and their typical applications, boaters can make informed decisions when selecting an outboard motor, ensuring a safe and enjoyable boating experience.

Storm Marine are able to supply the full range of Mercury Outboard Engines with a wide range of shaft lengths to suit your application - browse our outboard engines for sale page here.
